Control Device Management API

This is the API to use control devices (Keyboard, mouse and joysticks). More...

Functions
void	GfctrlGetRefByName (const char *name, tCtrlRef *ref)
	Get a control reference by its name. More...
const char *	GfctrlGetNameByRef (GfCtrlType type, int index)
	Get a control name by its reference. More...
tCtrlJoyInfo *	GfctrlJoyInit (void)
	Initialize the joystick control. More...
void	GfctrlJoyRelease (tCtrlJoyInfo *joyInfo)
	Release the tCtrlJoyInfo structure. More...
int	GfctrlJoyIsPresent (void)
	Check if a joystick is present. More...
int	GfctrlJoyGetCurrent (tCtrlJoyInfo *joyInfo)
	Get the joystick current values. More...
tCtrlMouseInfo *	GfctrlMouseInit (void)
	Initialize the mouse control. More...
void	GfctrlMouseRelease (tCtrlMouseInfo *mouseInfo)
	Release the tCtrlMouseInfo structure. More...
int	GfctrlMouseGetCurrent (tCtrlMouseInfo *mouseInfo)
	Get the mouse current values. More...
void	GfctrlMouseCenter (void)
	Recentre the mouse on the screen. More...
void	GfctrlMouseInitCenter (void)
	Get the reference position. More...
bool	GfctrlIsEventBlacklisted (void *parmHandle, const char *driversSection, const char *event)
	Check if given event is blacklisted (used for buttons or axis which fire a button AND move event). More...
void	GfuiMouseSetHWPresent (void)
	Force the hardware mouse pointer. More...

Detailed Description

This is the API to use control devices (Keyboard, mouse and joysticks).

Function Documentation

GfctrlGetNameByRef()

const char* GfctrlGetNameByRef	(	GfCtrlType	type,
		int	index
	)

Get a control name by its reference.

Parameters

type	type of control
index	reference index

Returns

pointer on a static structure tCtrlRef

Definition at line 191 of file control.cpp.

GfctrlGetRefByName()

void GfctrlGetRefByName	(	const char *	name,
		tCtrlRef *	ref
	)

Get a control reference by its name.

Parameters

name	name of the control
ref	Pointer to tCtrlRef to fill in

See also

tCtrlRef

Definition at line 123 of file control.cpp.

GfctrlIsEventBlacklisted()

bool GfctrlIsEventBlacklisted	(	void *	parmHandle,
		const char *	driversSection,
		const char *	event
	)

Check if given event is blacklisted (used for buttons or axis which fire a button AND move event).

Parameters

parmHandle	Parameters containing the blacklist
driversSection	Specific parameter section
event	Name of the event, usually obtaned with GfctrlGetRefByName, e.g. "BTN7-0"

Returns

true if blacklisted, false otherwise

Definition at line 502 of file control.cpp.

Here is the call graph for this function:

GfctrlJoyGetCurrent()

int GfctrlJoyGetCurrent

(

tCtrlJoyInfo *

joyInfo

)

Get the joystick current values.

Parameters

joyInfo

joystick structure

Returns

0 ... Ok
-1 .. Error

Note

The tCtrlJoyInfo structure is updated with the new values

Definition at line 349 of file control.cpp.

GfctrlJoyInit()

tCtrlJoyInfo* GfctrlJoyInit

(

void

)

Initialize the joystick control.

Returns

pointer on a tCtrlJoyInfo structure
0 .. if no joystick present

Note

call GfctrlJoyRelease to free the tCtrlJoyInfo structure

See also

GfctrlJoyRelease

tCtrlJoyInfo

Definition at line 303 of file control.cpp.

Here is the call graph for this function:

GfctrlJoyIsPresent()

int GfctrlJoyIsPresent

(

void

)

Check if a joystick is present.

Returns

GFCTRL_JOY_NONE if no joystick
GFCTRL_JOY_PRESENT if a joystick is present

Definition at line 332 of file control.cpp.

Here is the call graph for this function:

GfctrlJoyRelease()

void GfctrlJoyRelease

(

tCtrlJoyInfo *

joyInfo

)

Release the tCtrlJoyInfo structure.

Parameters

joyInfo

joystick structure

Returns

none

Definition at line 321 of file control.cpp.

GfctrlMouseCenter()

void GfctrlMouseCenter

(

void

)

Recentre the mouse on the screen.

Returns

none

Definition at line 476 of file control.cpp.

Here is the call graph for this function:

GfctrlMouseGetCurrent()

int GfctrlMouseGetCurrent

(

tCtrlMouseInfo *

mouseInfo

)

Get the mouse current values.

Parameters

mouseInfo

mouse structure

Returns

0 ... Ok
-1 .. Error

Note

The tCtrlMouseInfo structure is updated with the new values

Definition at line 427 of file control.cpp.

Here is the call graph for this function:

GfctrlMouseInit()

tCtrlMouseInfo* GfctrlMouseInit

(

void

)

Initialize the mouse control.

Returns

pointer on a tCtrlMouseInfo structure
0 .. if no mouse present

Note

call GfctrlMouseRelease to free the tCtrlMouseInfo structure

See also

GfctrlMouseRelease

Definition at line 399 of file control.cpp.

GfctrlMouseInitCenter()

void GfctrlMouseInitCenter

(

void

)

Get the reference position.

Returns

none

Definition at line 489 of file control.cpp.

Here is the call graph for this function:

GfctrlMouseRelease()

void GfctrlMouseRelease

(

tCtrlMouseInfo *

mouseInfo

)

Release the tCtrlMouseInfo structure.

Parameters

mouseInfo

mouse structure

Returns

none

Definition at line 412 of file control.cpp.

GfuiMouseSetHWPresent()

void GfuiMouseSetHWPresent

(

void

)

Force the hardware mouse pointer.

Returns

0 ... Ok
-1 .. Error

Definition at line 241 of file gui.cpp.
